Benefits

• Have an Extra Eye on Your Printer: Experience the new Revo detection system thanks to our patented 3-point piezoelectric sensor. Integrated seamlessly with the Phrozen GO App, it’s connected 24/7 to your phone for timely monitoring.
• Smart Residue Detection: Avoid breaking your LCD screen due to cured particles in the vat. The sensor will cue the printer to stop printing once it detects any foreign objects between the building plate and the release film upon its initial descent.*
  *The sensors will detect objects ≥ 4mm.
• Smart Failure Detection: Get notified of possible failure early in both your printer and your phone (through the Phrozen GO App) when the sensors detect abnormalities during printing.
  *Notifications will be triggered once sensors detect the complete absence of peeling force for 15 continuous layers, after the building plate is no longer submerged in resin.
• Keep It Under Control, Even on the GO: Monitor your print on the go or stop printing upon the earliest detection of failure, all from the palm of your hand.

Model credit @blackforge_games

Specs

• System: Phrozen OS
• Operation: 5-inch Touch Panel
• Slicer Software: CHITUBOX V1.9.6 and above (or others)
• Connectivity: USB | Wi-Fi
• Built-in Memory: 8.0 GB
• Technology: Resin 3D Printer - LCD Type
• Light Source: Linear Projection LED Module
• XY Resolution: 16.8µm x 24.8 µm
• Layer Thickness: 0.01 - 0.30 mm
• Avg. Printing Speed: 450 layers/hr
• Release Film: nFEP Film
• Compatible File Format: CTB / PRZ
• Power Requirement: 100–240V AC;50–60Hz
• Printer Size: 35.3 × 34.5 × 51.7 cm
• Printing Volume: 22.3 x 12.6 x 23.5 cm
• Printer Weight: 18 kg

*All specifications have been tested in a laboratory. Please note that certain specifications may be subject to change without prior notice.
