Sonic Mini 8K - The Most #EPIC8K LCD 3D Printer

With the highest resolution of 22 µm and 1152 ppi, Sonic Mini 8K surpasses all consumer electronics on the market.The 7.1” LCD screen & 18 cm Z-axis are perfect for printing all sorts of extremely intricate miniatures, bust sculpts, and more!

Both North American & European Adapters will be provided with the Sonic Mini 8K. If either adapter is not designated for use in your country or region, please feel free to purchase your own.

Model credit @3dartdigital

Check also: Phrozen Sonic Mini Resin 4K.

Benefits

• 22 µm (1152 ppi) Ultra-High Resolution: Prints beyond handcrafted models
• 7.1” Mono LCD Screen: Larger printing space with 18 cm Z-axis
• Ultra-Stable Dual Linear Rails: Prints high-quality models with extreme stability
• Frosted Laser Cut Building Plate: Allows models to attach firmly onto the building plate
• Linear Projection LED Module: Enhances light uniformity to create superb & sharp models

Specs

• System: Phrozen OS
• Operation: 3.5" in Large Touch Panel
• Slicer Software: CHITUBOX V1.9.0 or above
• Connectivity: Front USB Port
• Design: Technology Resin 3D Printer - LCD Type
• Light Source: Linear ProjectionLED Module
• Release Film:FEP Film
• XY Resolution: 22 µm
• Layer Thickness: 0.01-0.30 mm
• Maximum Printing Speed: 80 mm/hr
• Power Requirement: DC 24V ; 3A
• System Power: 50 W
• Printer Size: 29 x 29 x 43 cm
• Print Volume:16.5 x 7.2 x 18 cm
• Printer Weight: 13 kg

*All specifications have been tested in a laboratory. Please note that certain specifications may be subject to change.
